提示词
{
"type": "scientific hardware diagram",
"layout": {
"main_scene": "3D render of an optical table with a red laser beam passing through 11 aligned optical components mounted on black posts.",
"top_brackets": [
{"label": "Dual Modulation", "span": "SLM1"},
{"label": "4f Relay Optics", "span": "Lens L1 to Lens L2"},
{"label": "Imaging Optics", "span": "SLM2 to Lens L4"},
{"label": "Detection", "span": "Camera"}
],
"optical_components_left_to_right": [
{"name": "Laser", "labels": ["Laser", "λ = {argument name=\"laser wavelength\" default=\"632.8 nm\"}"]},
{"name": "SLM1", "labels": ["SLM1", "(Phase / Pol. Mod.)"]},
{"name": "Lens L1", "labels": ["Lens L1", "(f1)"]},
{"name": "Iris", "labels": ["Fourier Plane", "(Pupil Plane)", "Iris", "(Higher Orders Filtered)"]},
{"name": "HWP", "labels": ["HWP", "(λ/2)"]},
{"name": "Lens L2", "labels": ["Lens L2", "(f1)"]},
{"name": "SLM2", "labels": ["SLM2", "(Phase / Pol. Mod.)"]},
{"name": "Lens L3", "labels": ["Lens L3", "(f2)"]},
{"name": "Lens L4", "labels": ["Lens L4", "(f2)"]},
{"name": "Linear Polarizer", "labels": ["Linear", "-Polarizer", "(Global Analyzer)"]},
{"name": "Polarization Camera", "labels": ["POLARIZATION CAMERA"]}
],
"inset_box": {
"position": "bottom right",
"title": "Polarization Camera Micro-Polarizer Array (Per-Pixel Analyzer)",
"grid": "4x4 grid of colored squares with directional arrows",
"legend_count": 4,
"legend_items": [
"Red square, horizontal arrow, 0° (H)",
"Green square, vertical arrow, 90° (V)",
"Blue square, diagonal arrow, 45° (D)",
"Yellow square, diagonal arrow, 135° (A)"
]
},
"bottom_caption": {
"figure_prefix": "{argument name=\"figure number\" default=\"Fig. 5.\"}",
"title": "{argument name=\"system name\" default=\"Ellipsography Hardware Setup.\"}",
"text": "Paragraph of scientific text explaining the dual-modulation configuration, 4f relay optics, and polarization camera."
}
}
}译文
{
"type": "科学硬件图",
"layout": {
"main_scene": "3D渲染的光学平台，其中一条红色激光束穿过安装在黑色支柱上的11个对齐的光学元件。",
"top_brackets": [
{"label": "双调制", "span": "SLM1"},
{"label": "4f中继光学", "span": "透镜L1到透镜L2"},
{"label": "成像光学", "span": "SLM2到透镜L4"},
{"label": "检测", "span": "相机"}
],
"optical_components_left_to_right": [
{"name": "激光", "labels": ["激光", "λ = {argument name=\"laser wavelength\" default=\"632.8 nm\"}"]},
{"name": "SLM1", "labels": ["SLM1", "(相位/偏振调制)"]},
{"name": "透镜L1", "labels": ["透镜L1", "(f1)"]},
{"name": "光阑", "labels": ["傅里叶平面", "(瞳孔平面)", "光阑", "(高阶滤波)"]},
{"name": "HWP", "labels": ["HWP", "(λ/2)"]},
{"name": "透镜L2", "labels": ["透镜L2", "(f1)"]},
{"name": "SLM2", "labels": ["SLM2", "(相位/偏振调制)"]},
{"name": "透镜L3", "labels": ["透镜L3", "(f2)"]},
{"name": "透镜L4", "labels": ["透镜L4", "(f2)"]},
{"name": "线性偏振器", "labels": ["线性", "-偏振器", "(全局分析器)"]},
{"name": "偏振相机", "labels": ["POLARIZATION CAMERA"]}
],
"inset_box": {
"position": "bottom right",
"title": "偏振相机微偏振器阵列（每像素分析器）",
"grid": "4x4彩色方块网格，带有方向箭头",
"legend_count": 4,
"legend_items": [
"红色方块，水平箭头，0° (H)",
"绿色方块，垂直箭头，90° (V)",
"蓝色方块，对角箭头，45° (D)",
"黄色方块，对角箭头，135° (A)"
]
},
"bottom_caption": {
"figure_prefix": "{argument name=\"figure number\" default=\"Fig. 5.\"}",
"title": "{argument name=\"system name\" default=\"Ellipsography Hardware Setup.\"}",
"text": "一段科学文字，解释双调制配置、4f中继光学和偏振相机。"
}
}
}
